State-first composition with dragmapr

explodemap computes the geometry of an exploded layout. Manual composition – nudging regions and labels until the map reads well – belongs to the dragmapr editor. The bridge between them is a single, reusable composition object: a dragmapr_state.

The workflow is compute once, then compose and render from the state:

explode_grouped()  ->  as_dragmapr_state()  ->  dragmapr_edit()  ->  focus_map(state = )
   (geometry)            (handoff)                (compose)            render_dragged_map(state = )

1. Compute the layout

library(explodemap)

# A few regions, each with several units.
unit_square <- function(x0, y0, size = 40000) {
  sf::st_polygon(list(rbind(
    c(x0, y0), c(x0 + size, y0), c(x0 + size, y0 + size),
    c(x0, y0 + size), c(x0, y0)
  )))
}

grid <- expand.grid(col = 0:2, row = 0:2)
regions <- sf::st_sf(
  region = rep(c("A", "B", "C"), each = 3),
  unit   = sprintf("u%02d", seq_len(9)),
  geometry = sf::st_sfc(
    lapply(seq_len(9), function(i) unit_square(grid$col[i] * 50000, grid$row[i] * 50000)),
    crs = 3857
  )
)

layout <- explode_grouped(regions, region_col = "region")
#> Level 1: Applying local explosion (alpha_l = 65587 m)...
#> Level 2: Computing anchor positions (mode = auto)...
#> Applying anchor displacement...

plot(layout)

2. Hand the layout over as a state

as_dragmapr_state() is the preferred handoff. It converts the exploded anchors into metre deltas and records the projected CRS plus a geometry_id, so the result is a durable, reproducible composition:

state <- as_dragmapr_state(layout)
state
#> $level
#> [1] "region"
#>
#> $region_offsets
#>   region dx_m dy_m
#> 1      A    0    0
#> 2      B    0    0
#> 3      C    0    0
#>
#> $label_offsets
#> [1] label_id region   dx_m     dy_m
#> <0 rows> (or 0-length row.names)
#>
#> $expanded_groups
#> character(0)
#>
#> $view
#> NULL
#>
#> $version
#> [1] 0
#>
#> $crs
#> [1] 3857
#>
#> $geometry_id
#> [1] "Grouped Layout"
#>
#> $selected_feature
#> NULL
#>
#> attr(,"class")
#> [1] "dragmapr_state"

The older as_dragmapr() returns a raw dragmapr_layout (geometry plus offset tables). It remains supported as a low-level escape hatch, but as_dragmapr_state() is the recommended entry point.

3. Compose

Open the dragmapr editor seeded with the state. In Shiny, capture each edit back into a state with dragmapr::dragmapr_widget_state():

dragmapr::dragmapr_edit(layout, state = state)

4. Render the composed state

Every downstream renderer accepts the state via state =. The interactive focus map can even reopen on a saved selection with restore_selection = TRUE:

state$selected_feature <- "B"
focus_map(layout, state = state, group_col = "region", restore_selection = TRUE)

And the static renderer reproduces the composition from geometry plus state, with no recomputation:

dragmapr::render_dragged_map(
  layout$sf_grouped,
  region_col = "region",
  state = state,
  file = "composed.png"
)

The state also flows through update_exploded_layout(), so an edited composition can be folded back onto the grouped layout object itself.

For a complete runnable script, see system.file("examples/state_first_workflow.R", package = "explodemap").

For a fuller cross-package example that includes layout diagnostics, label-aware parameter search, a simulated editorial pass, JSON state persistence, focus_map(), and dragmapr::render_dragged_map(), run:

source(system.file(
  "examples/explodemap_dragmapr_pipeline.R",
  package = "explodemap"
))
