Overview

explode_grouped() extends the core two-level exploded-map workflow with a three-level hierarchy for multi-region or national-scale layouts.

This grouped extension is most useful when a standard two-level explosion still leaves region blocks visually crowded or difficult to compare across a larger spatial extent.

The three levels are:

Level 1 — Local explosion. Units within each parent region are displaced using the centroid-driven field from the core algorithm. The geometric guarantees of Propositions 1–3 apply at this level.
Level 2 — Radial anchor placement. Parent region centroids are displaced radially outward from the national centroid to generate initial anchor positions for each region block.
Level 3 — Collision-aware refinement (optional). Overlapping anchors are iteratively repelled while a spring term maintains proximity to the original radial targets.

Levels 2 and 3 preserve structural grouping and directional correspondence rather than topological coverage. The formal geometric guarantees of Propositions 1–3 apply strictly at Level 1.

library(sf)
#> Linking to GEOS 3.12.1, GDAL 3.8.4, PROJ 9.4.0; sf_use_s2() is TRUE
library(explodemap)

A synthetic grouped example

We create a small dataset with six units in three regions, spread across a wider spatial extent than the two-region example in vignette("getting-started").

sq <- function(xmin, ymin, size = 1000) {
  st_polygon(list(matrix(
    c(xmin, ymin,
      xmin + size, ymin,
      xmin + size, ymin + size,
      xmin, ymin + size,
      xmin, ymin),
    ncol = 2,
    byrow = TRUE
  )))
}

geom <- st_sfc(
  sq(0, 0), sq(3000, 0),       # R1
  sq(9000, 0), sq(12000, 0),   # R2
  sq(24000, 0), sq(27000, 0),  # R3
  crs = 3857
)

x <- st_sf(
  id     = paste0("u", 1:6),
  region = c("R1", "R1", "R2", "R2", "R3", "R3"),
  geometry = geom
)

Anchor modes

explode_grouped() supports three anchor placement modes:

Mode	Description
`"auto"`	Level 2 only — radial placement without collision resolution
`"auto_collision"`	Level 2 + Level 3 — radial placement with iterative refinement
`"manual"`	User-supplied anchor coordinates

Automatic grouped layout

The simplest call uses mode = "auto":

g_auto <- explode_grouped(
  x,
  region_col = "region",
  mode       = "auto",
  plot       = FALSE
)
#> Level 1: Applying local explosion (alpha_l = 2410 m)...
#> Level 2: Computing anchor positions (mode = auto)...
#> Applying anchor displacement...

class(g_auto)
#> [1] "grouped_exploded_map" "exploded_map"         "list"
print(g_auto)
#>
#> -- Grouped Layout (grouped) ------------------------------
#>   n units   :  6
#>   n regions :  3
#>   mode      :  auto
#>   alpha_l   :  2.4 km
#>   p         :  1.25
#>   kappa     :  1.8
#>   padding   :  50 km

The result is a grouped_exploded_map S3 object, which also inherits from exploded_map:

names(g_auto)
#> [1] "sf_orig"        "sf_local"       "sf_grouped"     "sf_grouped_wgs"
#> [5] "stats"          "params"         "anchors"        "plots"
#> [9] "diagnostics"

Plot the grouped layout:

plot(g_auto)

Collision-aware grouped layout

mode = "auto_collision" adds Level 3 refinement. Overlapping region blocks are iteratively repelled while a spring term pulls them back toward their radial targets:

g_collide <- explode_grouped(
  x,
  region_col = "region",
  mode       = "auto_collision",
  plot       = FALSE
)
#> Level 1: Applying local explosion (alpha_l = 2410 m)...
#> Level 2/3: Computing anchor positions (mode = auto_collision)...
#> Anchor solver reached max iterations (60). Layout may have residual overlaps.
#> Applying anchor displacement...

plot(g_collide)

The anchor table reports the resulting block radii and coordinates:

g_collide$anchors[, c("region", "block_radius", "anchor_x", "anchor_y")]
#> # A tibble: 3 × 4
#>   region block_radius anchor_x anchor_y
#>   <chr>         <dbl>    <dbl>    <dbl>
#> 1 R1            3910.  -76471.      500
#> 2 R2            3910.  -53887.      500
#> 3 R3            3910.  102879.      500

Viewing all stages

plot(g, "all") shows the original, locally exploded, and grouped layouts side by side:

plot(g_collide, "all")

Inspecting anchor positions

layout_regions() computes anchor positions as a standalone step, which is useful for custom workflows or manual adjustment:

anchors <- layout_regions(
  x,
  region_col = "region",
  mode       = "auto"
)

anchors[, c("region", "block_radius", "n_units", "anchor_x", "anchor_y")]
#> # A tibble: 3 × 5
#>   region block_radius n_units anchor_x anchor_y
#>   <chr>         <dbl>   <int>    <dbl>    <dbl>
#> 1 R1             1500       2  -73279.      500
#> 2 R2             1500       2  -57079.      500
#> 3 R3             1500       2  102879.      500

Manual anchors

You can edit anchor positions and pass them back into explode_grouped():

manual_anchors <- anchors
manual_anchors$anchor_x <- manual_anchors$anchor_x + c(0, 500, 1000)
manual_anchors$anchor_y <- manual_anchors$anchor_y + c(0, 250, 500)

g_manual <- explode_grouped(
  x,
  region_col = "region",
  mode       = "manual",
  anchors    = manual_anchors,
  plot       = FALSE
)
#> Level 1: Applying local explosion (alpha_l = 2410 m)...
#> Level 2: Computing anchor positions (mode = manual)...
#> Applying anchor displacement...

plot(g_manual)

Key parameters

Level 1 parameters control local displacement within regions:

Parameter	Default	Purpose
`alpha_l`	derived	Local expansion magnitude (metres)
`p`	1.25	Distance-scaling exponent
`gamma_l`	1.136	Local clearance coefficient (used if `alpha_l` is NULL)

Level 2 and Level 3 parameters control anchor placement and refinement:

Parameter	Default	Purpose
`kappa`	1.8	Radial expansion factor
`padding`	50000	Base padding (map units)
`delta`	15000	Log-density scaling factor
`lambda`	0.18	Spring coefficient for refinement
`eta`	0.18	Repulsion step size for refinement
`padding_sep`	20000	Minimum separation between blocks

For real-world data, these defaults are tuned for national-scale U.S. layouts such as states grouped into larger reporting regions. For smaller or larger extents, adjust padding, delta, and padding_sep to match your coordinate system and visual scale.

Summary

summary(g_collide)
#>
#> Grouped Exploded Map Summary
#> ============================
#> Dataset:      Grouped Layout
#> Units:        6
#> Regions:      3
#> Grouped by:   region
#> Anchor mode:  auto_collision
#>
#> Level 1 Parameters
#>   alpha_l:  2.4 km   (local expansion)
#>   p:        1.25
#>
#> Anchor Parameters
#>   kappa:        1.8
#>   padding:      50 km
#>   delta:        15 km
#>   lambda:       0.18
#>   eta:          0.18
#>
#> Anchor Radii
#> # A tibble: 3 × 3
#>   region block_radius n_units
#>   <chr>         <dbl>   <int>
#> 1 R1            3910.       2
#> 2 R2            3910.       2
#> 3 R3            3910.       2

What the grouped object stores

Field	Contents
`sf_orig`	Original input geometries
`sf_local`	Geometries after Level 1 local explosion
`sf_grouped`	Final geometries after anchor displacement
`sf_grouped_wgs`	Final geometries in WGS84 (EPSG:4326)
`stats`	Geometry statistics from `compute_stats()`
`params`	All parameters used
`anchors`	Anchor table with block radii and positions
`plots`	ggplot objects for original, local, and grouped layouts
`diagnostics`	Label, region column, centroid mode, and anchor mode

Scope of guarantees

The local explosion stage (Level 1) preserves the package’s core geometric guarantees: exact feature-level geometry preservation (Proposition 1), radial ordering within regions (Proposition 2), and bounded displacement (Proposition 3).

The grouped anchor stage (Levels 2–3) is a higher-level layout extension. It preserves grouping structure and directional correspondence rather than topological coverage.

Next steps

For the core two-level workflow and parameter derivation, see vignette("getting-started").

For full paper-scale examples including cross-state calibration, Canada, and HHS grouped layouts, see vignette("reproducing-paper-examples").
